AF88 FR Fire Resistant Door
CATEGORY
Doors
Description
The AluFlam AF88 FR fire‑rated door system delivers premium performance for applications requiring enhanced structural depth and EI60 fire resistance. Featuring an 88 mm system depth, it supports thicker fire‑resistant glazing while retaining slim, elegant aluminium profiles.
Suitable for internal and external use, the AF88 system is available in single or double door configurations and can be supplied in inward or outward opening versions. The thermally broken aluminium frames are engineered for strength, durability, and long‑term performance in demanding environments.
With compatibility for concealed, surface‑mounted, or roller hinges and a wide choice of finishes, the AF88 FR system combines flexibility with robust fire protection. It is an ideal choice for commercial buildings where safety, performance, and architectural quality are equally important.
- OVERVIEW
- TECHNICAL DATA
| Double Door AF88 FR | |
|---|---|
| Performances | |
| U value W/m²K (Double glazing) : | - |
| U value W/m²K (Triple glazing) : | Ud = 1.44 |
| Air tightness (Pa) : | Class 2 |
| Water tightness (Pa) : | 5A (200Pa) |
| Wind load (Pa) : | C3 (1200Pa) |
| Security PAS 24 : | RC2 |
| Size limits | |
| Maximum door leaf size : | 1380x2645 |
| Features | |
| Sightline (Jamb) : | 700x1800 |
